Beschrijving
| Artikelnummer | O/D inch | O/D mm | A | B | C | H | R | WxT | Bout afmeting | Fy (kN) 80ºC | Gewicht (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 66.704.ST0022.1 | 1/2 | 21,3 | 31 | 46 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,37 |
| 66.704.ST0027.1 | 3/4 | 26,9 | 34 | 49 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,40 |
| 66.704.ST0034.1 | 1 | 33,7 | 37 | 52 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,42 |
| 66.704.ST0049.1 | 1 1/2 | 48,3 | 45 | 60 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,57 |
| 66.704.ST0061.1 | 2 | 60,3 | 52 | 67 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,58 |
| 66.704.ST0089.1 | 3 | 88,9 | 65 | 80 | 10 | 12 | 7 | 40x5 | M10x40 | 5,1 | 0,70 |
| 66.704.ST0115.1 | 4 | 114,3 | 78 | 93 | 11 | 12 | 7 | 40x5 | M10x40 | 4,7 | 0,83 |
| 66.704.ST0169.1 | 6 | 168,3 | 107 | 122 | 11 | 12 | 9 | 40x5 | M10x40 | 4,5 | 1,07 |
| 66.704.ST0220.1 | 8 | 219,1 | 132 | 147 | 11 | 12 | 9 | 50x6 | M10x40 | 4,5 | 1,99 |
| 66.704.ST0273.1 | 10 | 273,0 | 159 | 174 | 14 | 12 | 9 | 50x6 | M10x40 | 3,6 | 2,37 |
| 66.704.ST0324.1 | 12 | 323,9 | 190 | 208 | 14 | 14 | 12 | 50x6 | M12x50 | 6,2 | 2,83 |
| 66.704.ST0356.1 | 14 | 355,6 | 206 | 224 | 14 | 14 | 12 | 60x8 | M12x50 | 6,2 | 5,05 |
| 66.704.ST0407.1 | 16 | 406,4 | 231 | 249 | 18 | 14 | 12 | 60x8 | M12x50 | 6,2 | 5,65 |
| 66.704.ST0458.1 | 18 | 457,2 | 257 | 275 | 18 | 14 | 12 | 60x8 | M12x50 | 5,9 | 6,35 |
