Beschrijving
| Artikelnummer | O/D inch | O/D mm | A | B | C | H | R | WxT | Bout afmeting | Fy (kN) 80ºC | Gewicht (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 66.175.ST0022.1 | 1/2 | 21,3 | 32 | 51 | 12 | 12 | 5 | 25x3 | M10x45 | 3,8 | 0,19 |
| 66.175.ST0027.1 | 3/4 | 26,9 | 32 | 51 | 12 | 12 | 5 | 25x3 | M10x45 | 3,8 | 0,20 |
| 66.175.ST0034.1 | 1 | 33,7 | 38 | 57 | 12 | 12 | 5 | 25x3 | M10x45 | 3,8 | 0,22 |
| 66.175.ST0043.1 | 1 1/4 | 42,4 | 44 | 63 | 12 | 12 | 5 | 25x3 | M10x45 | 3,8 | 0,23 |
| 66.175.ST0049.1 | 1 1/2 | 48,3 | 51 | 70 | 12 | 12 | 9 | 30x6 | M10x45 | 6,1 | 0,50 |
| 66.175.ST0061.1 | 2 | 60,3 | 57 | 76 | 16 | 14 | 9 | 30x6 | M12x50 | 7,6 | 0,57 |
| 66.175.ST0077.1 | 2 1/2 | 76,1 | 70 | 89 | 16 | 14 | 9 | 30x6 | M12x50 | 7,6 | 0,68 |
| 66.175.ST0089.1 | 3 | 88,9 | 76 | 96 | 16 | 14 | 9 | 30x6 | M12x50 | 7,6 | 0,75 |
| 66.175.ST0102.1 | 3 1/2 | 101,6 | 83 | 102 | 16 | 14 | 9 | 30x6 | M12x50 | 7,6 | 0,82 |
| 66.175.ST0115.1 | 4 | 114,3 | 95 | 119 | 20 | 18 | 9 | 40x6 | M16x65 | 7,6 | 1,22 |
| 66.175.ST0140.1 | 5 | 139,7 | 114 | 138 | 20 | 18 | 9 | 40x6 | M16x65 | 7,6 | 1,36 |
| 66.175.ST0169.1 | 6 | 168,3 | 127 | 157 | 24 | 22 | 15 | 40x10 | M20x80 | 12,1 | 2,10 |
| 66.175.ST0220.1 | 8 | 219,1 | 159 | 189 | 24 | 22 | 15 | 40x10 | M20x80 | 12,1 | 3,22 |
| 66.175.ST0273.1 | 10 | 273,0 | 190 | 226 | 27 | 27 | 18 | 50x12 | M24x100 | 18,2 | 5,90 |
| 66.175.ST0324.1 | 12 | 323,9 | 216 | 252 | 27 | 27 | 18 | 50x12 | M24x100 | 18,2 | 6,56 |
| 66.175.ST0356.1 | 14 | 355,6 | 235 | 271 | 27 | 27 | 18 | 65x12 | M24x100 | 18,2 | 9,18 |
| 66.175.ST0407.1 | 16 | 406,4 | 260 | 296 | 27 | 27 | 18 | 65x12 | M24x100 | 18,2 | 10,01 |
| 66.175.ST0458.1 | 18 | 457,2 | 298 | 334 | 27 | 27 | 23 | 65x15 | M24x100 | 22,7 | 13,49 |
| 66.175.ST0508.1 | 20 | 508,0 | 324 | 360 | 27 | 27 | 23 | 65x15 | M24x100 | 22,7 | 17,00 |
| 66.175.ST0610.1 | 24 | 609,6 | 387 | 432 | 34 | 33 | 23 | 80x15 | M30x120 | 22,7 | 24,00 |
